Article: DMC-000040757
ASRock B850 LiveMixer WiFi Motherboard 90-MXBQU0-A0UAYZ

ASRock B850 LiveMixer WiFi Motherboard

A motherboard for assembling or upgrading a compatible desktop computer. It brings the main components together and provides the foundation for a well-planned system build.

Characteristics
Component type
Motherboard
Processor socket
AM5
Supported memory type
DDR5
Motherboard chipset
AMD B850
Processor | Supported processor sockets
Socket AM5
Processor | Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor | Processor manufacturer
AMD
Graphics | Parallel processing technology support
Not supported
Graphics | HDCP
Yes
Graphics | Maximum resolution
3840 x 2160 pixels
Features | Certification
FCC, CE, ErP/EuP
Features | Product colour
Black
Features | Motherboard chipset family
AMD
Features | Audio chip
Realtek ALC1220
Features | Windows operating systems supported
Windows 10 x64, Windows 11 x64
Features | Audio output channels
7.1 channels
Features | Motherboard form factor
ATX
Memory | Number of memory slots
4
Memory | Memory slots type
DIMM
Memory | Supported memory types
DDR5-SDRAM
Memory | Maximum internal memory
256 GB
Memory | Unbuffered memory
Yes
Memory | ECC сompatibility
ECC & Non-ECC
Memory | Memory channels
Dual-channel
Weight & dimensions | Depth
244 mm
Weight & dimensions | Width
305 mm
Network | Bluetooth version
5.4
Network | Ethernet interface type
2.5 Gigabit Ethernet
Network | Ethernet LAN
Yes
Network | Wi-Fi
Yes
Network | Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Network | Bluetooth
Yes
Network | LAN controller
Dragon RTL8125BG
Network | Wi-Fi standards
802.11a, Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Internal I/O | 12V power connector
Yes
Internal I/O | RGB LED pin header
Yes
Internal I/O | Number of chassis fan connectors
3
Internal I/O | Number of CPU fan connectors
2
Internal I/O | USB 2.0 connectors
2
Internal I/O | TPM connector
Yes
Internal I/O | CPU fan connector
Yes
Internal I/O | Number of SATA III connectors
2
Internal I/O | EPS power connector (8-pin)
Yes
Internal I/O | Front panel audio connector
Yes
Internal I/O | USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
Internal I/O | Number of EPS power connectors (8-pin)
1
Internal I/O | ATX Power connector (24-pin)
Yes
Internal I/O | USB 3.2 Gen 2x2 connectors
1
Internal I/O | Number of water pump connectors
1
Internal I/O | Number of RGB LED pin headers
4
BIOS | BIOS type
UEFI AMI
Packaging content | Antenna included
Yes
Packaging content | Cables included
SATA
Storage controllers | Supported storage drive interfaces
PCI Express 4.0, PCI Express 5.0, SATA III
Storage controllers | RAID support
Yes
Storage controllers | RAID levels
10, 1, 0
Storage controllers | Number of storage drives supported
5
Storage controllers | Supported storage drive types
HDD & SSD
Rear panel I/O ports | Headphone outputs
1
Rear panel I/O ports | WiFi-AP antenna jack
2
Rear panel I/O ports | S/PDIF out port
Yes
Rear panel I/O ports | DisplayPort version
1.4
Rear panel I/O ports | USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
Rear panel I/O ports | Ethernet LAN (RJ-45) ports
1
Rear panel I/O ports | HDMI version
2.1
Rear panel I/O ports | HDMI ports quantity
1
Rear panel I/O ports | USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
Rear panel I/O ports | USB 2.0 ports quantity
8
Rear panel I/O ports | USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Rear panel I/O ports | USB connector type
USB Type-A, USB Type-C
Rear panel I/O ports | DisplayPorts quantity
1
Rear panel I/O ports | Microphone in
Yes
Expansion slots | PCI Express x16 (Gen 4.x) slots
2
Expansion slots | PCI Express x16 (Gen 5.x) slots
1
Expansion slots | Number of M.2 (M) slots
3
Expansion slots | 2nd M.2 highest PCI Express generation
4.0
Expansion slots | 3rd M.2 highest PCI Express generation
4.0
Expansion slots | 1st M.2 largest key size
2280
Expansion slots | 1st M.2 highest PCI Express generation
5.0
Expansion slots | 2nd M.2 largest key size
2280
Expansion slots | 3rd M.2 largest key size
2280
Safety warning | Warnings
Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
