Article: DMC-000040734
ASRock B850M Riptide WiFi Motherboard 90-MXBS30-A0UAYZ

ASRock B850M Riptide WiFi Motherboard

ASRock B850M Riptide WiFi Motherboard has the AM5 processor socket. It also has the AMD B850 chipset.

Characteristics
Component type
Motherboard
Processor socket
AM5
Supported memory type
DDR5
Motherboard chipset
AMD B850
Processor | Supported processor sockets
Socket AM5
Processor | Processor manufacturer
AMD
Processor | Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics | HDCP
Yes
Graphics | Maximum resolution
3840 x 2160 pixels
Graphics | Parallel processing technology support
Not supported
Features | Certification
FCC, CE, ErP/EuP
Features | Audio chip
Realtek ALC1220
Features | Motherboard form factor
micro ATX
Features | Motherboard chipset family
AMD
Features | Product colour
Black
Features | Windows operating systems supported
Windows 11 x64, Windows 10 x64
Features | Audio output channels
7.1 channels
Memory | Memory slots type
DIMM
Memory | Supported memory types
DDR5-SDRAM
Memory | Number of memory slots
4
Memory | Memory channels
Dual-channel
Memory | Maximum internal memory
256 GB
Memory | ECC сompatibility
ECC & Non-ECC
Memory | Unbuffered memory
Yes
Weight & dimensions | Width
244 mm
Weight & dimensions | Depth
244 mm
Network | Bluetooth
Yes
Network | Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Network | Wi-Fi standards
802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Network | Ethernet interface type
2.5 Gigabit Ethernet
Network | LAN controller
Dragon RTL8125BG
Network | Bluetooth version
5.4
Network | Ethernet LAN
Yes
Network | Wi-Fi
Yes
Internal I/O | ATX Power connector (24-pin)
Yes
Internal I/O | TPM connector
Yes
Internal I/O | Number of SATA III connectors
4
Internal I/O | CPU fan connector
Yes
Internal I/O | 12V power connector
Yes
Internal I/O | RGB LED pin header
Yes
Internal I/O | Front panel audio connector
Yes
Internal I/O | EPS power connector (8-pin)
Yes
Internal I/O | USB 3.2 Gen 1 (3.1 Gen 1) connectors
3
Internal I/O | Number of chassis fan connectors
3
Internal I/O | Number of EPS power connectors (8-pin)
1
Internal I/O | Number of CPU fan connectors
2
Internal I/O | USB 2.0 connectors
2
Internal I/O | Number of RGB LED pin headers
1
BIOS | BIOS type
UEFI AMI
Packaging content | M.2 standoff included
Yes
Packaging content | Antenna included
Yes
Packaging content | Cables included
SATA
Packaging content | Screws included
Yes
Storage controllers | RAID levels
10, 1, 0
Storage controllers | Supported storage drive interfaces
PCI Express 4.0, PCI Express 5.0, SATA III
Storage controllers | RAID support
Yes
Storage controllers | Number of storage drives supported
7
Storage controllers | Supported storage drive types
HDD & SSD
Rear panel I/O ports | Line-in
Yes
Rear panel I/O ports | DisplayPort version
1.4
Rear panel I/O ports | USB connector type
USB Type-A, USB Type-C
Rear panel I/O ports | USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Rear panel I/O ports | USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
Rear panel I/O ports | HDMI ports quantity
1
Rear panel I/O ports | Headphone outputs
3
Rear panel I/O ports | WiFi-AP antenna jack
2
Rear panel I/O ports | USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Rear panel I/O ports | Ethernet LAN (RJ-45) ports
1
Rear panel I/O ports | HDMI version
2.1
Rear panel I/O ports | USB 2.0 ports quantity
4
Rear panel I/O ports | Microphone in
Yes
Rear panel I/O ports | DisplayPorts quantity
1
Expansion slots | 1st M.2 highest PCI Express generation
5.0
Expansion slots | PCI Express x8 (Gen 4.x) slots
1
Expansion slots | Number of M.2 (M) slots
3
Expansion slots | PCI Express x16 (Gen 5.x) slots
1
Expansion slots | 2nd M.2 largest key size
2280
Expansion slots | 3rd M.2 highest PCI Express generation
4.0
Expansion slots | 2nd M.2 highest PCI Express generation
4.0
Expansion slots | 1st M.2 largest key size
2580
Expansion slots | 3rd M.2 largest key size
2280
Safety warning | Warnings
Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
