ASUS Power supply unit 90YE00W8-B0NA00 Black ATX 850 W 80 PLUS Platinum

ASUS Power supply unit 90YE00W8-B0NA00 Black ATX

ASUS Power supply unit 90YE00W8-B0NA00 ATX is a power supply for building or upgrading a compatible desktop computer. It delivers power to the system components and supports a tidy, dependable PC setup.

Characteristics
80 PLUS certification
80 PLUS Platinum
Total power
850 W
Product colour
Black
PSU form factor
ATX
Component type
Power supply unit
Design | Cooling type
Active
Design | Number of fans
1 fan(s)
Design | Fan location
Top
Design | On/off switch
Yes
Power | Combined power (+5Vsb)
15 W
Power | Max output current (+5V)
25 A
Power | Max output current (+12V)
70.8 A
Power | Max output current (+5Vsb)
3 A
Power | Combined power (-12V)
3.6 W
Power | Max output current (+3.3V)
25 A
Power | Combined power (+5V)
130 W
Power | Combined power (+3.3V)
130 W
Power | Power Factor Correction (PFC) type
Active
Power | Power protection features
Overheating, Short circuit, Over voltage, Over power, Under power, Over current
Power | AC input voltage
100 - 240 V
Weight & dimensions | Width
160 mm
Weight & dimensions | Depth
150 mm
Weight & dimensions | Height
86 mm
Weight & dimensions | Weight
1.78 kg
Performance | Power supply unit (PSU) form factor
ATX
Performance | Purpose
PC
Performance | ATX version
3.1
Performance | Mean time between failures (MTBF)
120000 h
Performance | Bearing technology
DBB
Packaging data | Package type
Box
Packaging data | Package height
108 mm
Packaging data | Package depth
200 mm
Packaging data | Package weight
3.51 kg
Packaging data | Package width
320 mm
Packaging content | Cables included
CPU, PCIe, SATA, Peripheral (Molex)
Ports & interfaces | SATA power cable length
400, 120 mm
Ports & interfaces | PCI Express power cable length
75 cm
Ports & interfaces | Motherboard power connector
20+4 pin ATX
Ports & interfaces | Peripheral (Molex) power cable length
150, 400 mm
Ports & interfaces | CPU power cable length
100 cm
Ports & interfaces | Number of SATA power connectors
6
Ports & interfaces | Motherboard power cable length
61 cm
Ports & interfaces | CPU power connector (4+4 pin)
Yes
Ports & interfaces | PCI Express power connectors (16-pin)
1
Ports & interfaces | Peripheral (Molex) power connectors (4-pin)
3
Ports & interfaces | PCI Express power connectors (6+2 pin)
4
Ports & interfaces | Cabling type
Fully-Modular
