Article: DMC-000032674
Intel® Core™ i5-12400 Processor Boxed

Intel® Core™ i5-12400 Processor Boxed

Intel® Core™ i5-12400 Processor is a processor for building or upgrading a compatible computer. It forms the core of the system and supports responsive everyday work across compatible applications.

Characteristics
Processor model
i5-12400
Processor socket
LGA 1700
Processor cores
6 count
Processor threads
12 count
Package edition
Boxed
Technical details | Launch date
Q1'22
Technical details | OpenCL version
2.1
Technical details | Status
Launched
Technical details | Target market
Gaming
Processor | Processor family
Intel® Core™ i5
Processor | Processor cache
18 MB
Processor | Processor operating modes
64-bit
Processor | Processor manufacturer
Intel
Processor | Box
Yes
Processor | Cooler included
Yes
Processor | Bus type
DMI4
Processor | Processor cache type
Smart Cache
Processor | Memory bandwidth supported by processor (max)
76.8 GB/s
Processor | Processor codename
Alder Lake
Processor | Processor base power
65 W
Processor | Performance cores
6
Processor | Performance-core base frequency
2.5 GHz
Processor | Processor generation
12th gen Intel® Core™ i5
Processor | Performance-core boost frequency
4.4 GHz
Processor | Maximum number of DMI lanes
8
Processor | Maximum turbo power
117 W
Graphics | On-board graphics card
Yes
Graphics | Discrete graphics card
No
Graphics | On-board graphics card ID
0x4692 / 0x4682
Graphics | On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
5120 x 3200 pixels
Graphics | Number of execution units
24
Graphics | On-board graphics card outputs supported
DisplayPort 1.4a, HDMI 2.1, Embedded DisplayPort (eDP) 1.4b
Graphics | On-board graphics card dynamic frequency (max)
1450 MHz
Graphics | On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
Graphics | On-board graphics card maximum resolution (HDMI)
4096 x 2160 pixels
Graphics | On-board graphics card base frequency
300 MHz
Graphics | On-board graphics card model
Intel UHD Graphics 730
Graphics | On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
Graphics | On-board graphics card OpenGL version
4.5
Graphics | On-board graphics card DirectX version
12.0
Graphics | Number of displays supported (on-board graphics)
4
Graphics | On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
Graphics | On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
Graphics | Multi-Format Codec Engines
1
Features | Export Control Classification Number (ECCN)
5A992CN3
Features | Thermal Monitoring Technologies
Yes
Features | Execute Disable Bit
Yes
Features | Harmonized System (HS) code
8542310001
Features | PCI Express configurations
1x16+1x4, 2x8+1x4
Features | CPU configuration (max)
1
Features | Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Features | PCI Express slots version
5.0, 4.0
Features | Market segment
Desktop
Features | Scalability
1S
Features | Maximum number of PCI Express lanes
20
Features | Commodity Classification Automated Tracking System (CCATS)
G167599
Features | Idle States
Yes
Features | Direct Media Interface (DMI) Revision
4.0
Features | Use conditions
PC/Client/Tablet
Memory | Memory bandwidth (max)
76.8 GB/s
Memory | Memory channels
Dual-channel
Memory | Memory types supported by processor
DDR5-SDRAM, DDR4-SDRAM
Memory | Maximum internal memory supported by processor
128 GB
Operational conditions | Tjunction
100 °C
Weight & dimensions | Processor package size
45 x 37.5 mm
Processor special features | Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Processor special features | Intel Virtualization Technology (VT-x)
Yes
Processor special features | Enhanced Intel SpeedStep Technology
Yes
Processor special features | Intel® Volume Management Device (VMD)
Yes
Processor special features | Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Processor special features | Intel® OS Guard
Yes
Processor special features | Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Processor special features | Intel® AES New Instructions (Intel® AES-NI)
Yes
Processor special features | Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Processor special features | Mode-based Execute Control (MBE)
Yes
Processor special features | Intel Turbo Boost Max Technology 3.0
No
Processor special features | Intel® Boot Guard
Yes
Processor special features | Intel® Secure Key
Yes
Processor special features | Intel 64
Yes
Processor special features | Intel® Optane™ Memory Ready
Yes
Processor special features | Intel® Speed Shift Technology
Yes
Processor special features | Intel® Quick Sync Video Technology
Yes
Processor special features | Intel VT-x with Extended Page Tables (EPT)
Yes
Processor special features | Intel® Turbo Boost Technology
2.0
Processor special features | Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Yes
Processor special features | Intel® Control-flow Enforcement Technology (CET)
Yes
Processor special features | Intel® Thread Director
No
Other features | Maximum internal memory
128 GB
Other features | Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
Safety warning | Warnings
Do not dispose of the processors in the normal rubbish bin - they require special disposal due to their potential environmental impact.
